🔩 User interface board Repair Guide for Electrolux EFME517STT
💡 Don’t panic! User interface board on your Electrolux EFME517STT dryer is a common issue that many DIY enthusiasts successfully repair. This comprehensive guide will walk you through each step with detailed explanations to help you diagnose and fix the problem safely and effectively. 🎉 You’ve got this!
🔧 Required Tools & Parts
- User interface board
- Ribbon cable
📝 Pro Tip: Gather all your tools and parts before starting. This saves time and prevents frustration mid-repair. Most of these parts can be found online or at appliance parts stores. Make sure you have the correct model number when ordering parts! ✔️ Double-check compatibility before purchasing.
⚠️ Safety First!
⚠️ Always disconnect power before working on your dryer. Electrical safety is non-negotiable. If you’re working with gas dryers, also shut off the gas supply. If you’re unsure about any step, consult a professional technician. Your safety is more important than saving a few dollars! ⚠️ When in doubt, call a pro!
✔️ Step-by-Step Repair Instructions
🔌
🔧 Step 1: Disconnect power
- Locate the dryer’s power cord at the back of the unit, positioned in the center bottom section approximately 8-10 inches from the floor.
- Grasp the dryer’s side panels and pull the unit forward away from the wall 24-36 inches to create working space behind it.
- Look at the wall outlet – this is a 240-volt, 4-prong outlet (NEMA 14-30R configuration) with four rectangular slots arranged in an L-shape.
- Grip the power cord plug firmly where the rubber molding meets the hard plastic plug body (not by pulling the cord itself).
- Pull the plug straight out from the wall outlet using steady, firm pressure. The plug will release after moving 1-2 inches outward.
- Visually confirm the plug is completely separated from the wall outlet – no prongs should remain inserted.
- Coil the power cord and drape it over the top back edge of the dryer to keep it off the floor and prevent tripping.
- Walk to your home’s electrical panel (circuit breaker box).
- Locate the double-pole 30-amp breaker labeled “Dryer” or “Electric Dryer” – this breaker will be twice the width of standard single breakers.
- Flip this breaker to the OFF position – the toggle switch will move from the center or right position to the left position.
- Place a piece of tape over the breaker and write “DRYER REPAIR – DO NOT TURN ON” on the tape using a permanent marker.
- Return to the dryer and verify the drum light does not illuminate when you open the door – this confirms power disconnection is successful.
- Press the dryer’s power button multiple times – the control panel display should remain completely dark with no lights, sounds, or responses.
🔧
🛠️ Step 2: Remove control panel
- Locate the two Phillips-head screws at the top of the control panel, positioned approximately 2 inches from each end of the panel width.
- Use a Phillips-head screwdriver #2 to remove both screws completely, rotating counterclockwise 8-10 full turns per screw.
- Set the screws aside in a container to prevent loss.
- Grip the control panel at both ends with your hands positioned at the outer edges.
- Pull the top of the control panel forward approximately 1-2 inches, tilting it away from the dryer body at a 30-degree angle.
- Lift the panel upward while maintaining the tilted angle until the bottom tabs (located at 3 inches from each end of the bottom edge) disengage from the slots in the dryer top.
- Rotate the control panel forward to rest it face-down on top of the dryer, allowing it to hang by the attached wire harnesses.
- Identify the main wire harness connector on the right side of the control board—a white rectangular plastic connector approximately 2 inches wide with 8-10 multi-colored wires.
- Press the locking tab on top of the white connector using your thumb while pulling the connector straight out from the control board socket with your other hand.
- Locate the door switch wire connector on the left side—a smaller white connector approximately 1 inch wide with 2-3 wires.
- Disconnect this second connector by pressing its release tab and pulling straight out.
- Set the control panel completely aside on a clean, flat surface with the display facing up to prevent scratching.
🔍
⚙️ Step 3: Check ribbon cable connection
- Locate the control board assembly behind the control panel at the top front of the dryer, measuring approximately 24 inches wide by 4 inches tall.
- Identify the ribbon cable—a flat, beige or gray cable approximately 1 inch wide with multiple thin copper traces visible through translucent insulation—connecting the user interface board to the main control board.
- Examine the connector at the user interface board end (top board), which sits in a white or black plastic socket positioned on the right side of the board, approximately 2 inches from the edge.
- Press down on the small plastic locking tabs located on each side of the connector using your thumb and index finger while pulling the ribbon cable straight out with your other hand.
- Inspect the ribbon cable for damage: look for any creases, tears, darkened burn marks, or areas where the copper traces appear broken or separated.
- Check the exposed copper contact strips at the cable end—there should be 8 to 12 individual metallic lines running across the width, each appearing bright and unoxidized.
- Examine both connector sockets on the boards for bent pins (tiny metal contacts inside the white plastic housing) or debris like lint or dust.
- Use compressed air to blow out both connector sockets, holding the can upright 3-4 inches away from the socket opening.
- Reinsert the ribbon cable into the user interface board socket by aligning the cable straight with the socket opening and pushing firmly until the locking tabs click into place on both sides.
- Repeat steps 4 through 9 for the opposite end of the ribbon cable where it connects to the main control board.
- Verify proper seating by attempting to gently pull the cable straight out—it should not release without pressing the locking tabs.
- Confirm the cable sits flat with no twists or sharp bends along its length between the two boards.
🔍
🔩 Step 4: Inspect UI board
- Locate the UI (User Interface) board, which is the circuit board mounted directly behind the control panel display at the top front of the dryer, measuring approximately 8 inches wide by 3 inches tall.
- Examine the board surface under good lighting, holding a flashlight at a 45-degree angle to highlight any surface abnormalities.
- Look for these specific failure indicators on the green circuit board:
- Inspect the 3 wire harness connectors on the board’s left side:
- Check the touchpad ribbon cable connector (flat, transparent cable entering the board’s right side) for proper seating—the cable should sit flush with no gaps visible between cable and connector housing.
- Examine all visible solder joints on the board’s back side by tilting the control panel forward—look for gray, dull, or cracked solder versus shiny, smooth dome-shaped joints.
- Test board functionality by pressing each button on the control panel while observing the LED display—all buttons should respond with corresponding display changes or beeps.
- If you found burn marks, bulging capacitors, or cracked solder joints, the board requires replacement (part number 137557600).
- If the board appears visually intact but buttons don’t respond, proceed to electrical testing in the next step.
âś…
đź“‹ Step 5: If unresponsive, replace
- Order replacement door switch assembly part number 137353310 (verify your model uses this part by matching the 4-wire connector configuration and mounting tab positions on your existing switch).
- Remove the white wire connector from the bottom terminal of the old switch by pulling straight down with steady pressure until it releases.
- Remove the blue wire connector from the left terminal by pulling horizontally away from the switch body.
- Remove the orange wire connector from the top terminal by pulling straight up.
- Remove the black wire connector from the right terminal by pulling horizontally away from the switch body.
- Press the release tab on the bottom of the switch housing using a flat-head screwdriver, pushing inward approximately 1/4 inch while simultaneously pulling the entire switch assembly forward and out of the door frame mounting bracket.
- Position the new door switch assembly by aligning the two mounting tabs (one at top, one at bottom) with the corresponding slots in the door frame bracket located 3 inches down from the top door edge.
- Push the switch housing firmly into the bracket until you hear an audible click, confirming the bottom release tab has locked into place.
- Connect the white wire to the bottom terminal by pushing the connector straight onto the terminal until it bottoms out and cannot be pulled off without significant force.
- Connect the blue wire to the left terminal, pushing until seated completely.
- Connect the orange wire to the top terminal, pushing until seated completely.
- Connect the black wire to the right terminal, pushing until seated completely.
- Test the mechanical function by pressing the small white actuator button on the front of the switch 10 times rapidly—you should feel distinct clicks with each press and release.
- Verify all four wire connections remain firmly seated after the actuation test.
âś…
âś… Step 6: Install new UI board
- Remove the new UI board (part number 137006090) from its antistatic bag by tearing open the sealed end.
- Hold the new UI board with both hands, positioned so the button side faces outward and the connector tabs point toward the dryer cabinet.
- Align the two plastic clips on the back of the UI board with the matching slots in the metal control panel frame, located at the top edge of the board, spaced 8 inches apart.
- Insert the top edge of the UI board into the frame first, angling it at approximately 30 degrees.
- Push the bottom of the board toward the frame until you hear two distinct clicks, confirming both top clips have engaged.
- Press firmly along the bottom edge of the UI board until the four bottom tabs snap into place—you’ll feel each one click individually.
- Locate the white 12-pin ribbon cable connector you previously disconnected, hanging approximately 4 inches below the UI board mounting area.
- Align the ribbon cable connector with the matching socket on the back of the UI board, positioned at the center-left, 2 inches from the left edge.
- Push the ribbon cable connector straight into the socket until it clicks audibly and sits flush against the board—no gap should be visible between connector and socket.
- Locate the smaller 6-pin wire harness connector with red, black, white, blue, yellow, and green wires.
- Insert this connector into the remaining socket on the right side of the UI board, 3 inches from the right edge, pushing firmly until it clicks into place.
- Verify both connectors are fully seated by gently tugging on each cable—neither should pull free with moderate pressure of 2-3 pounds of force.
- Press each button on the UI board once to confirm none are stuck or binding against the control panel frame.
🧪
🔍 Step 7: Test all controls
- Plug the dryer power cord into the 240V outlet and push the dryer back to within 6 inches of its final position, leaving enough space to access the rear panel if needed.
- Open the dryer door and verify it closes smoothly with an audible click when the latch engages with the striker on the cabinet frame.
- Press the Power button located at the top-left of the control panel and verify the display screen illuminates with “PUSH TO START” or a similar ready message.
- Turn the cycle selector knob clockwise through each position (Normal, Delicates, Heavy Duty, Steam Refresh, etc.) and confirm the display changes to show each cycle name and default settings.
- Press each function button on the control panel (Temperature, Dryness Level, Signal, Delay Start, Options) one at a time and verify the corresponding indicator lights illuminate or settings change on the display.
- Select the Air Fluff cycle (no heat setting), press the Start button, and verify the drum begins rotating counterclockwise when viewing from the front.
- Open the door mid-cycle to confirm the drum stops rotating immediately when the door switch disengages.
- Close the door, press Start again, and verify the cycle resumes within 2-3 seconds.
- Press the Pause button and confirm the drum stops while the display remains lit showing time remaining.
- Select Normal Dry cycle, set temperature to High, press Start, and run for 3-4 minutes while listening for unusual scraping, squealing, or grinding noises from the drum or motor area.
- Place your hand near the lint screen opening after 2 minutes of heated operation and verify warm air is flowing out steadily.
- Press Power to turn off the dryer and verify all lights and the display turn off completely.
- Push the dryer into its final position against the wall with the exhaust duct properly connected.
